Compare: 2026 Elves MORI GTX 49 vs 2025 TWITTER Bikes Gravel G2 Base S

Insights

Average stack and reach vs trend of all-road/gravel bikes

Design deviates from other sizes of Elves MORI

Average stack and reach vs trend of all-road/gravel bikes

Design deviates from other sizes of TWITTER Bikes Gravel G2

Stack	536.8mm	564mm +27.2mm
Reach	371.1mm	373mm +1.9mm
Stack to Reach Ratio	1.45:1	1.51:1
Seat Tube Length, C-T	460mm	—
Seat Tube Length, Unknown	—	450mm
Top Tube Length, Effective/Horizontal HT Top	520mm	—
Top Tube Length, Effective/Horizontal Unknown	—	535mm
Top Tube Slope	10.7deg	14.8deg +4.1deg
Head Tube Angle	71.5deg	71.8deg +0.3deg
Seat Tube Angle	74.5deg	74deg -0.5deg
Head Tube Length	110mm	140mm +30mm
Bottom Bracket Drop	69mm	70mm +1mm
Bottom Bracket Height	287mm	279mm -8mm
Chainstay Length	430mm	435mm +5mm
Chainstay Length Horizontal	424.4mm	429.3mm +4.9mm
Front-Center	584.3mm	587mm +2.7mm
Front-Center Horizontal	579.6mm	582.7mm +3.1mm
Wheelbase	1004mm	1012mm +8mm
Fork Offset/Rake	50mm	45mm -5mm
Fork Length (Axle-To-Crown)	400mm	—
Fork Length, Unknown	—	395mm
Trail	66.4mm high	67.4mm +1mm high
Mechanical Trail	63mm	64mm +1mm
Wheel Flop	20mm	20mm +0mm
Standover Height	732mm	729mm -3mm
Tire to Pedal Spindle	58.3mm 170 mm cranks	68mm +9.7mm 170 mm cranks
Pedal Spindle to Ground Clearance	117mm 170 mm cranks	109mm -8mm 170 mm cranks

Wheel Size	700C/29 in 622 mm BSD	700C/29 in 622 mm BSD
Tire Width	45mm	38mm -7mm
Tire Width Max	50mm	—
Tire Outer Diameter	712mm	698mm -14mm
Bike Length with Tires	1716mm	1710mm -6mm
Suspension Type	Rigid, non-suspension corrected	Rigid, non-suspension corrected
Bar Type	Drop Bar	Drop Bar
Frame Material	Carbon/Composite	Aluminum
Fork Material	Carbon/Composite	Carbon/Composite
Brake Type	Disc	Disc
